| SPECIFICATIONS | |
| Voltage rating | 250V AC, DC |
| Current rating | 7A, AC, DC |
| Withstanding Voltage | 1500V AC/minute |
| Insulation resistance | 1000MΩ min |
| Temperature range | -25°C~+85°C |
| Contact resistance | 20mΩ max |
| TERMINAL | |
| Part No. | T3961PT(L) |
| Applicable wire | AWG#16-#22 |
| Material | Phosphor Bronze |
| Finish | Tin Plated |
| HOUSING | |
| Part No. | H3961-NP(L) |
| Poles | 02-16P |
| Housing Material | Nylon66 UL94V-0 |
| WAFER | |
| Part No. | W3961V(R)-NP(W3961R-NP-FW)(W3961R-NP-DW-WL3.7)(W3961R-NP-DW-WL3.7)(W3961SV-NP) |
| Poles | 02-16P |
| Housing Material | Nylon66 UL94V-0 |
| Pin Material | Brass |
| Contact Area Plating | Tin-Plated |
